The HandiPrint 6017 printer is an ideal and low cost solution as a handheld portable POS printer. The Monarch HandiPrint 6017 Printer features an integrated magnetic card stripe reader and "cradles" Symbol SPT-1700 or PPT-2700 series Palm Pilot computers, and is capable of processing all credit card, debit card or loyalty card transactions anywhere inside or outside the retailer’s store.
 Monarch MO-6017 Portable Printer with Magnetic Card Reader - shown with SPT 1800/PPT2800 |
MO 6017 Models & Prices MO 6017 Features & Benefits MO 6017 Descriptions MO 6017 Applications MO 6017 Label Examples MO 6017 Specifications |
Back to Palm Pilot list| Part# | Description | |
| MON601701RCPT | Monarch Handiprint for Symbol SPT-1700, SPT-1800, PPT-2700 and PPT-2800 Palm Commputers, Includes Battery & AC Adapter | |
| MO601702RCPT | Monarch Handiprint, With Magnetic Stripe Reader, for Symbol SPT-1700, SPT-1800, PPT-2700 and PPT-2800 Palm Commputers, Includes Battery & AC Adapter | |
| 12029346 | SPT 1800 Cable | |
| 900295 | Receipt Paper for Monarch 6017, 10 Rolls / Case, 3.125" x 636" | |
| 900294 | Receipt Paper for Monarch 6017, 50 Rolls / Case, 3.125" x 636" |
| HandiPrint 6017 FEATURES | BENEFITS |
| Ergonomic design | Ergonomically-pleasing one-piece design cradles Symbol 1700/2700 series PDA, eliminating need for cables or cords |
| Lightweight | Lightweight design at under 2 lbs |
| Thermal direct printing | Thermal direct printing of clear, crisp 3" supplies including receipts (bar code and text |
| Battery | Rechargeable Lithium-Ion battery can print 2500 inches on a single charge |
| Magnetic Stripe Reader | Integrated magnetic card reader for fast credit card processing, and driver’s license swipes |
| Total Solution | Fits easily in the palm of your hand |
| Accessories | Accessories for belt clips and wall/table mounts |
| HANDIPRINT 6017 PRODUCT DESCRIPTIONS |
Portable POS Printing The HandiPrint 6017 printer is an ideal and low cost solution as a portable POS printer. Why the need for portable POS? With today’s fast-paced lifestyles, speed is of the essence. The faster a customer can be served, the more satisfied that customer will be. With the Monarch HandiPrint 6017 Printer, retailers can solve the age-old problem of long lines at peak times. The Monarch HandiPrint 6017 Printer features an integrated magnetic card stripe reader and “cradled” Symbol SPT-1700 or PPT-2700 series data collectors, and is capable of processing all credit card, debit card or loyalty card transactions anywhere inside or outside the four walls of a retailer’s store. The ergonomically pleasing one-piece design of the Handiprint Printer, eliminates expensive cables and slow, cumbersome technologies of more traditional two-piece data collector/printer designs. It also allows complete mobility of the PDA enabling the user to easily remove the data collector for other functions. The Monarch HandiPrint 6017 Printer also features Lithium-ion battery technology for increased capacity and less maintenance worries. Capable of printing up to 2500 inches on a single charge, the HandiPrint Printer can easily last an entire 8 hour shift without the need for reloading or recharging. Whatever your need for portable POS, the Monarch HandiPrint 6017 Printer can be your solution to faster and better customer service.
|
| HANDIPRINT 6017 PRODUCT APPLICATIONS |
The Handiprint 6017 Printer is small and light enough to be used comfortably in a handheld operation, and it prints bar codes and text with high-quality print resolution. The Handiprint 6017 printer offers tremendous gains in productivity and accuracy over handwriting forms, receipts, or prescriptions. Home-Based Businesses No more handwritten sales receipts at home parties! When combined with a handheld organizer, the Handiprint 6017 printer gives sales representatives the ability to scan bar coded products, process credit card transactions, print receipts, take orders electronically and upload to a computer at a later time. The benefits are timesavings, improved accuracy and better customer service. Route Delivery Route drivers deliver everything from snacks and cakes to beverages and tobacco products. Each customer requires a receipt for payment and each transaction requires data to update the system. The Monarch Handiprint 6017 printer is the ideal solution. In addition, route drivers can now upsell additional products with the ability to process credit card transactions. Home Repair Services The Handiprint 6017 printer is perfect for service repair personnel who may want the dual benefits of scanning bar coded parts for updating inventory while printing a receipt for the customer at the point-of-service. Again, personnel now have the ability to perform impluse services and process credit card payment on the spot. Healthcare Prescriptions and Lab Instructions Thousands of physicians are using handheld organizers. Add the scanning capabilities of the organizer and the printing convenience of the Handiprint 6017 printer, and you have a powerful device that scans bar coded prescription labels, prints prescriptions and produces lab test instruction tickets. Remote Parking Receipts The Handiprint 6017 printer makes it easy for remote parking lot attendants to keep track of parking sales while issuing payment receipts with lot locations. Fine and Ticket Issuing The Handiprint 6017 printer is an easy way for traffic and security officers to issue fines or tickets for illegally parked vehicles. In many cases, VIN numbers can be scanned from the windshield for tracking purposes, and parking tickets can be printed right on the spot. Payment could now also be processed on the spot.
|
| HANDIPRINT 6017 LABEL EXAMPLES | ||
 Home-Based Businesses Label Size: 3" x 4" (76.5 mm x 102 mm) |
 Route Delivery Label Size: 3" x 4" (76.5 mm x 102 mm) |
 Home Repair Services Label Size: 3" x 4" (76.5 mm x 102 mm) |
 Healthcare Prescriptions and Lab Instructions Label Size: 3" x 4" (76.5 mm x 102 mm) |
 Remote Parking Receipts Label Size: 3" x 4" (76.5 mm x 102 mm) |
 Fine and Ticket Issuing Label Size: 3" x 4" (76.5 mm x 102 mm) |
| HANDIPRINT 6017 SPECIFICATIONS |
| Standard Features | |
| Dimensions: | Height - 2.8" (71 mm) Width - 4.25" (108 mm) Length - 9.5" (241 mm) Weight (with battery and supplies) - 1.41 lb. (0.64 kg) |
| Printhead: | 2.83" (72 mm/576 dots) 203 dots/inch (8.0 dots/mm) |
| Interface Type: | Serial RS-232 |
| Regulatory: | • FCC Class A Part 15 • CE |
| Bar Code Symbologies: | Code 128, Code 39, Codabar, I 2 of 5, UCC/EAN/Code 128, and UPC/EAN/JAN |
| Memory: | 128K Flash, 32K SRAM |
| Options | |
| Magnetic Card Reader Printer Stand (120611) Belt Clip (120296) M09461™ Single-Station Battery Charger M09464™ Four-Station Battery Charger |
|
| Supplies | |
| Only Monarch supplies are recommended; use thermal direct stock. | |
| Supply Type: | Thermal Direct Receipt Paper |
| Supply Dimensions: | Thickness - 2.7 - 3.5 mils Width - 3.125" (79 mm) Length - • Minimum feed 1.0" (25.4 mm) •Maximum feed 8.0" (203 mm) • 1 roll is approximately 600" (15,240 mm) Roll Outside Diameter - 1.5" (38 mm) Coreless Inside Diameter - 0.25 (6 mm) |
| Performance | |
| Power: | 7.4V Lithium Ion Battery Prints while the battery is charging. Charges the handheld's battery while connected to the printer. |
| Battery Rate: | Prints 2,500" (63,500 mm) on a single charge |
| Printing Rate: | Up to 2" (51 mm) per second |
| Duty Cycle: | Prints up to 1,000" (25,400 mm) per day. The average print rate is 1 inch every 10 seconds at a text character print density of 25% (i.e., one character printed out of every four positions.) Bar codes and graphics need a lower duty cycle. |
| Warranty: | One (1) year parts and one (1) year labor, Depot Service |
| Environment Ranges | |
| Temperature: | Operating Thermal Direct - 41° to 104° F (5° to 40° C) Storage - 4° to 140° F (-20° to 60° C) |
| Humidity: | Operating - -20% to 85% non-condensing Storage - 5% to 95% non-condensing |
| Electrostatic Discharge and Air Quality: | Some problems with electronic equipment may occur in environments prone to static discharge or extreme dust conditions. Monarch suggests that you take precautions to minimize these problems. Contact your Monarch representative for recommended precautions. |
